Aluminum Alloy CNC Machining: 6061 vs 7075 vs 5052 Selection Guide



Aluminum is the most widely used metal in CNC machining — and for good reason. It is light, strong enough for most uses, easy to machine, resists corrosion, and costs much less than metals like titanium or stainless steel. Among the many aluminum alloys available, three are used most often for machined parts: 6061, 7075, and 5052.

Picking the right aluminum alloy is key to your project's success. The wrong choice can lead to parts that are too weak, too costly, hard to machine, or not fit for the working environment. This complete guide compares these three popular alloys across strength, machinability, corrosion resistance, cost, and best uses — helping you make the best material choice for your CNC machined aluminum parts.

This guide is based on 25+ years of aluminum CNC machining experience at Eastmaster Manufacturing in Shenzhen, where we process thousands of aluminum parts every year across all three alloys.

Why Aluminum Is the Top Metal for CNC Machining

Before comparing specific alloys, here is why aluminum is used more than any other metal in CNC machining:

    Easy to machine: Aluminum cuts 3-5× faster than steel, which means shorter cycle times and less tool wear

    Very light: At 2.7 g/cm³, aluminum weighs about one-third of steel — key for aerospace, automotive, and portable devices

    Good strength for its weight: Many aluminum alloys are as strong as mild steel at a fraction of the weight

    Resists corrosion: A natural oxide layer protects against rust; no plating needed for most uses

    Great thermal and electrical conductivity: Perfect for heat sinks, electrical boxes, and thermal management

    Low cost: Raw material is much cheaper than titanium, stainless steel, or engineering plastics like PEEK

    100% recyclable: Can be recycled with no loss of properties — important for sustainability-focused companies

    Works well with anodizing: Aluminum takes anodizing beautifully, giving both better corrosion resistance and color options

6061 Aluminum: The All-Round Workhorse

6061 is the most widely used aluminum alloy for general-purpose CNC machining. It gives the best balance of strength, machinability, weldability, and corrosion resistance — making it the go-to choice when no special performance need calls for another alloy.

Key Properties

Property	6061-T6	6061-O (Annealed)
Tensile Strength	310 MPa	124 MPa
Yield Strength	276 MPa	55 MPa
Hardness (Brinell)	95 HB	30 HB
Elongation	8-12%	25-30%
Density	2.70 g/cm³	2.70 g/cm³
Machinability Rating	65% (of 12L14 steel)	Lower due to softness
Corrosion Resistance	Good	Good
Weldability	Excellent	Excellent
Anodizing Response	Excellent	Good

Common Uses

    Aerospace fittings and brackets

    Automotive parts (suspension parts, engine mounts)

    Electronic enclosures and heat sinks

    Marine hardware and fittings

    Sporting goods (bicycle frames, baseball bats)

    General-purpose machine parts

    Prototypes and low-volume production parts

When to Choose 6061

    You need a good all-round alloy with no extreme requirements

    Welding or brazing is needed

    Good corrosion resistance is needed without extra treatment

    Anodizing is planned for looks or protection

    Cost matters — 6061 is usually the cheapest of the three

7075 Aluminum: The High-Strength Champion

7075 is one of the strongest aluminum alloys available, with strength close to many steels. It is the top choice for aerospace structures and other uses where the best strength-to-weight ratio matters most.

Key Properties

Property	7075-T6	7075-T73
Tensile Strength	572 MPa	503 MPa
Yield Strength	503 MPa	434 MPa
Hardness (Brinell)	150 HB	130 HB
Elongation	11%	13%
Density	2.81 g/cm³	2.81 g/cm³
Machinability Rating	70% (better than 6061 in T6)	Slightly lower
Corrosion Resistance	Fair (needs protection)	Good (stress-corrosion resistant)
Weldability	Poor (not recommended)	Fair
Anodizing Response	Good (but not as even as 6061)	Good

Common Uses

    Aircraft structural parts (wings, fuselage frames)

    Mold tooling (injection molds, blow molds)

    High-stress mechanical parts

    Spacecraft and missile parts

    High-performance bicycle and automotive parts

    Rock climbing equipment

    Firearms and defense parts

When to Choose 7075

    Maximum strength is the main requirement

    Weight savings are critical (aerospace, racing)

    The part will not be welded

    Corrosion can be managed through surface treatment (anodizing, painting, or cladding)

    You need a mold material with high hardness and good machinability

5052 Aluminum: The Formability and Corrosion Specialist

5052 is a non-heat-treatable aluminum-magnesium alloy known for its excellent formability, weldability, and top-level corrosion resistance — especially in marine environments. While not as common for CNC machining as 6061 or 7075, it does very well in certain uses.

Key Properties

Property	5052-H32	5052-H34
Tensile Strength	228 MPa	248 MPa
Yield Strength	193 MPa	214 MPa
Hardness (Brinell)	60 HB	65 HB
Elongation	12-16%	10-14%
Density	2.68 g/cm³	2.68 g/cm³
Machinability Rating	55% (lower than 6061)	Slightly lower
Corrosion Resistance	Excellent (especially saltwater)	Excellent
Weldability	Excellent	Excellent
Formability	Excellent	Good

Common Uses

    Marine parts (boat fittings, hulls, dock hardware)

    Fuel tanks and hydraulic lines

    Chemical processing equipment

    Sheet metal parts that need bending

    Medical equipment housings

    Food and beverage processing equipment

When to Choose 5052

    Top corrosion resistance is needed, especially in saltwater or chemical environments

    The part needs a lot of forming or bending in addition to machining

    Welding is needed and good weld strength is important

    Moderate strength is enough — 5052 is weaker than both 6061-T6 and 7075-T6

    The part will be used in marine or food-grade applications

6061 vs 7075 vs 5052: Full Comparison

Property	6061-T6	7075-T6	5052-H32
Tensile Strength	310 MPa	572 MPa ★	228 MPa
Weight	2.70 g/cm³ ★	2.81 g/cm³	2.68 g/cm³ ★
Machinability	Good (65%)	Very Good (70%) ★	Fair (55%)
Corrosion Resistance	Good	Fair	Excellent ★
Weldability	Excellent ★	Poor	Excellent ★
Formability	Good	Poor (in T6)	Excellent ★
Anodizing	Excellent ★	Good	Good
Cost	Lowest ★	Highest	Medium
Best For	General purpose	Maximum strength	Marine / forming

★ = Best in category

CNC Machining Tips for Aluminum Alloys

All three alloys can be machined well, but each has its own points to watch for the best results:

6061 Machining Tips

    Use sharp, polished carbide tools with high rake angles for the best surface finish

    Flood coolant is recommended for high-speed machining

    Watch for built-up edge (BUE) — keep tools sharp and use the right speeds

    T6 temper machines better than O temper (annealed is too gummy)

    Surface finish achievable: Ra 0.4-0.8 μm with proper tooling

7075 Machining Tips

    Higher cutting speeds possible than 6061 thanks to better machinability

    More abrasive than 6061 — expect slightly more tool wear

    Excellent surface finish possible — this is why it is preferred for mold tooling

    Avoid too much heat buildup, which can soften the material locally

    Tight tolerances achievable: ±0.02 mm is standard for precision work

5052 Machining Tips

    Softer and gummier than 6061 — use sharp tools with positive rake

    Lower cutting speeds to avoid built-up edge

    Chip control can be tricky — use chip-breaking geometries

    Great for parts that need both machining and bending

    Avoid heavy cuts in a single pass to prevent material deformation

Surface Treatment Options for Aluminum Alloys

Surface treatment improves appearance, corrosion resistance, and wear properties. Not all treatments work equally well on every alloy:

Treatment	6061	7075	5052
Anodizing (Type II)	Excellent ★	Good	Good
Hard Anodizing (Type III)	Excellent	Good	Good
Powder Coating	Excellent	Excellent	Excellent
Chemical Film (Alodine)	Excellent	Excellent ★	Excellent
Electroplating	Good	Fair	Good
Painting	Good	Good	Good

For more details, see our Surface Finish Guide for CNC Machined Parts.

How to Choose the Right Aluminum Alloy for Your Project

Use this simple decision guide to pick the best aluminum alloy:

    Is maximum strength the top priority? → 7075-T6

    Is the part for marine or chemical exposure? → 5052

    Does the part need to be welded? → 6061 or 5052 (avoid 7075)

    Does the part need a lot of bending or forming? → 5052

    Is anodizing quality very important? → 6061

    Is cost the main concern? → 6061

    Is the part a general-purpose part with no extreme requirements? → 6061 (default choice)

    Is it a mold or tooling application? → 7075-T6

Why Choose Eastmaster for Aluminum CNC Machining

Eastmaster Manufacturing has deep experience in CNC machining all aluminum alloys, from common 6061 to high-strength 7075 and marine-grade 5052. Our capabilities include:

    3, 4, and 5-axis CNC machining centers set up for aluminum

    High-speed spindles (up to 24,000 RPM) for top surface finishes

    Full range of aluminum alloys in stock: 6061, 7075, 5052, 2024, 5083, and more

    In-house anodizing coordination for Type II and Type III (hard) anodizing

    CMM inspection and full dimensional reporting

    ISO 9001 and ISO 13485 certified quality management

    D-U-N-S verified: 66-849-8033

From rapid prototypes to production runs of thousands of parts, our engineering team can help you pick the right aluminum alloy and improve your design for cost-effective CNC machining. Contact Eastmaster today for a fast, detailed quote — typically within 24 hours.
